- Unique Design: Both sides without servo ears of this micro servo, which provides enough space between the servo and the RC car, ensuring a smooth suspension movement. Design with IP65 Waterproof, only can splash water, please do not soak it in water for a long time
- Powerful Performance: The torque of the RC servo is up to 9.5kg-cm(335oz-in), and the speed is 0.085sec/60°. Meanwhile, the torque is 11kg-cm(388oz-in), and speed is 0.074sec/60° at 8.4V. Coreless servo provides fast response times to improve the overall agility of RC crawler
- Precision Control: Coreless servo is designed specifically to upgrade your vehicle's steering system, smoothly and precise movement ensures accurate steering, which is crucial for navigating obstacles and tricky terrain in RC crawling
- Good Quality: Built with CNC AL6061 aluminum case, 32-bit MCU and high-precision steel, which has high linearity and precision, more stable and low noise
- Great Choice: It is ideal for use in SCX 1/24 scale RC cars, crawlers, trucks and so on. Compatible with Sanwa SSR, NB4 and Futaba, which makes the micro servo a great choice for RC crawler enthusiasts looking for a blend of power, durability, and precision
Specification:
Torque/ Speed:
8.0kg-cm(282oz-in), 0.106sec/60° at 6.0V;
9.5kg-cm(335oz-in), 0.085sec/60° at 7.4V;
11kg-cm(388oz-in), 0.074sec/60° at 8.4V
Control System: PWM Control (1520usec in the central point)
Operation Voltage Range: DC6.0~8.4V
Operation Temperature Range: -20C°~ 70C°
Pulse Width: 500 to 2500 usec
Circle: ＞one million times without load
Operation Travel: 180°± 5°
Programmable Angle: YES
Direction: CW
Diver Type: Mos Drive
Motor Type: Coreless
Angle Sensor: Potentiometer
Single Type: Digital Control
Soft Start Function: Included
Mode Compatible: Sanwa SSR, NB4, Futaba
Waterproof Level: IP65
Dimension(mm): 23 x 12.6 x 27.0 mm
Weight(g): 22g±3g
Ball Bearing: 2BB
Gear Type: Straight
Case Material: Full Aluminum CNC
Connector Wire Length: 26AWG 180mm JR
Wire Info(Black): Negative
Wire Info(Black): Positive
Wire Info(White): S Single
