- [WIRELESS MOBILE MINI TRAVEL ROUTER] NanoPi R6S Mini Wifi Router can support external USB wifi adapter.Simultaneous dual band with wireless speed 300Mbps(2.4G) 433Mbps(5G).Convert a public network(wired/wireless) to a private Wi-Fi for secure surfing.
- [Open Source and Programmable] It can support FriendlyWrt, a custom system based on the OpenWrt distribution. It is open source and ideal for developing IoT applications, NAS applications, smart home gateways, and more.
- [DUAL PCIe 2.5G GBPS ETHERNET PORTS] The NanoPi R6S Mini Router has three 2.5Gbps Ethernet ports: one directly extended from the SoC and the other two converted from a PCIe. Gets around 941Mbits/second download and upload.
- [LARGER STORAGE & EXTENSIBILITY] with 64-bit 8GB LPDDR4X RAM at 2133MHz, 32GB Flash eMMC at HS400 mode and support MicroSD slot/UHS-I up to SDR104 mode; Support USB3.0 Host x1: USB Type A, USB 2.0 Host x1: USB Type A, USB-C x1; GPIO: 12-pin 0.5mm FPC connector; Debug UART x1, 3pin 2.54mm header; One Native Gigabit Ethernet and Dual PCIe 2.5G Gigabit Ethernet ports (1 WAN and 2 LAN).
- [OS/Software] NanoPi R6S Mini Portable Travel Router Running Android TV 12, Debian 10 Desktop, FriendlyWrt 22.03, Ubuntu 22.04 LTS Desktop, FriendlyCore Focal Lite(Base on Ubuntu 20.04); Kernel version: Linux-5.10-LTS/U-boot-2017.09.
- [8K Video Decoders and Encoders] Support 8K@60fps H.265 and VP9 decoder, 8K@30fps H.264 decoder, 4K@60fps AV1 decoder, 8K@30fps H.264 and H.265 encoder.
- [Embedded Custom Development] Nanopi R6S wifi router is very suitable for enterprise customers to customize and develop mini machine vision systems with multiple network ports, and it is also suitable for embedded enthusiasts to discover, explore and create their own unique gameplay.
- [USER MANUAL] WiKi:"youyeetoo.com/blog/nanopi-r6s-ysdpnanor6sa-209". Pls feel free to email us to get the Datasheet or any questions of this module after you purchased it. How to email us? Click ''forum.youyeetoo.com/'' and ask a question.
